Invisible Handles by NoHa
The INVI Hardware® No-Ha 2.0 integrates the door handle and magnetic latch in one box. INVI Hardware No-Ha 2.0 enables doors to be opened and shut without a visible door handle.
The handle is completely hidden by giving the cover plate the same finish as the door and walls. Available from stock.
FEATURES
For sliding door the NO-HA Slide is available:
For door thickness 38mm and more
NS 200: 38mm – 42mm
NS 205: 43mm – 47mm
NS 210: 48mm – 50mm
NS 105 for single use or 50mm+ doors (no lock or latch with this)
or a No-Ha Single handle for use on cabinetry and furniture (Note: a minimum thickness of 18mm is required – please see the installation instructions for more detail).
The INVI Hardware® No-Ha cover plate is not part of the mechanism so that it can be made to match the finish of the door panel. The INVI Hardware® No-Ha cover plate is available as an accessory in MDF or in brushed stainless steel.
When specifying the No-Ha Slide, please note that an edge/end pull must be fitted into the leading end of the sliding door so that when it is hidden within the pocket and you have something to get hold of to pull it.
FAQ
INVI Jamb is screw fixed to the jamb studs and header with flat headed screws (through the perforated sides) every 200mm into the wall stud, double screws in top corners and on hinges points, becoming a solid part of the wall structure.
INVI Jamb® is the original door jamb system that eliminates architraves, giving you that subtle, contemporary, clean line look. It’s durable, it’s affordable and is at home in commercial offices and showrooms, quality homes and public spaces like hospitals and schools.
- 1x Left hand door stile
- 1x Right hand door stile
- 1x Header
- 1x Head joiner (EZC only)
- Lift off channel (For EZC with Lift Off hinges only)
- Hardware kit including:
- Hinges
- 1x Latch plate
- 1x Plastic latch insert
- Hinge screws
INVI Jamb is fitted after the plaster lining has been installed, and has 35mm perforated sides for flush finishing with top coat into the walls, achieving clean architrave free lines around the doorway.
INVI Concept products are manufactured from zinc annealed steel and meet the finished surfaces standard AS/NZS 2311:2009 to ensure it can be painted immediately with standard wall paints, without any special preparation, so long as it is free of dust, dirt and oil.
Yes, architraves can be fitted, but the INVI Jamb concept is designed to create an ‘architrave-free’ opening.
INVI Jamb can be used with a variety of concealed and non-mortised hinges. Stainless Stainless steel INVI Jamb Herline hinges are provided with each door frame (lift off hinges are available if required).
Yes, INVI Jamb can be used with a solid core door. You will need to make sure that you are using the correct hinge and quantity to accommodate the door weight, making sure the hinge screws penetrate through to the timber stud behind the jamb, so that the weight of the door is swinging off the stud, and not off the INVI Jamb.
Plaster around the edges of the INVI Jamb will not crack if the INVI Jamb is installed according to the installation guide — i.e. must be screwed off every 200mm and double screwed at the hinge points and top corners. INVI Jamb then becomes an integral part of the wall.
Yes, custom made INVI Jambs are available with no header for full height doors.
Yes, masonry wall installation instructions are available contact sales@ezconcept.com.au for more details.
The manufacturer strongly recommends a timber stud or a 0.75 BMT metal stud on both sides of the opening.
EZC – The latch plate is surface mounted on the INVI Jamb Classic Adjust frame.
SRC – The latch plate is recessed into the frame for the INVI Jamb Single Rebate (SRC).
INVI Concept products are manufactured from highest quality zinc annealed cold-formed steel sections.
INVI Jamb frames are not welded and are clipped together using a unique INVI Jamb system that ensures an easy install and smooth finish.
- Key Features
-
FEATURES
The No-Ha door handle is recessed into the door panel and can be used on hinged/swing and sliding doors. The INVI Hardware® No-Ha 2.0 is available as a latch set to suit a hinged door, or as a latch set with a Cartel bathroom privacy lock. No-Ha Mini – Only NM 938 S5 availableFor sliding door the NO-HA Slide is available:
For door thickness 38mm and more
NS 200: 38mm – 42mm
NS 205: 43mm – 47mm
NS 210: 48mm – 50mm
NS 105 for single use or 50mm+ doors (no lock or latch with this)
or a No-Ha Single handle for use on cabinetry and furniture (Note: a minimum thickness of 18mm is required – please see the installation instructions for more detail).
The INVI Hardware® No-Ha cover plate is not part of the mechanism so that it can be made to match the finish of the door panel. The INVI Hardware® No-Ha cover plate is available as an accessory in MDF or in brushed stainless steel.
When specifying the No-Ha Slide, please note that an edge/end pull must be fitted into the leading end of the sliding door so that when it is hidden within the pocket and you have something to get hold of to pull it.
- Resources
- FAQ
-
FAQ
How is the INVI Jamb fixed?INVI Jamb is screw fixed to the jamb studs and header with flat headed screws (through the perforated sides) every 200mm into the wall stud, double screws in top corners and on hinges points, becoming a solid part of the wall structure.What is so Unique about the INVI Jamb Flush Door Jamb?INVI Jamb® is the original door jamb system that eliminates architraves, giving you that subtle, contemporary, clean line look. It’s durable, it’s affordable and is at home in commercial offices and showrooms, quality homes and public spaces like hospitals and schools.
What's included in the INVI Jamb frame kit?- 1x Left hand door stile
- 1x Right hand door stile
- 1x Header
- 1x Head joiner (EZC only)
- Lift off channel (For EZC with Lift Off hinges only)
- Hardware kit including:
- Hinges
- 1x Latch plate
- 1x Plastic latch insert
- Hinge screws
How is the architrave-free INVI Jamb fitted with plaster walls?INVI Jamb is fitted after the plaster lining has been installed, and has 35mm perforated sides for flush finishing with top coat into the walls, achieving clean architrave free lines around the doorway.
Do I have to use any special paint or preparation methods on INVI Concept products?INVI Concept products are manufactured from zinc annealed steel and meet the finished surfaces standard AS/NZS 2311:2009 to ensure it can be painted immediately with standard wall paints, without any special preparation, so long as it is free of dust, dirt and oil.
Can I fit architraves with the INVI Jamb system?Yes, architraves can be fitted, but the INVI Jamb concept is designed to create an ‘architrave-free’ opening.
What hinges should be used with INVI Jamb?INVI Jamb can be used with a variety of concealed and non-mortised hinges. Stainless Stainless steel INVI Jamb Herline hinges are provided with each door frame (lift off hinges are available if required).
Can INVI Jamb be used if I have a soild core door?Yes, INVI Jamb can be used with a solid core door. You will need to make sure that you are using the correct hinge and quantity to accommodate the door weight, making sure the hinge screws penetrate through to the timber stud behind the jamb, so that the weight of the door is swinging off the stud, and not off the INVI Jamb.
Will plaster crack around the edges of the INVI Jamb?Plaster around the edges of the INVI Jamb will not crack if the INVI Jamb is installed according to the installation guide — i.e. must be screwed off every 200mm and double screwed at the hinge points and top corners. INVI Jamb then becomes an integral part of the wall.
Can INVI Jamb be used in a doorway with no header?Yes, custom made INVI Jambs are available with no header for full height doors.
Can INVI Jamb be used with masonry or brick walls?Yes, masonry wall installation instructions are available contact sales@ezconcept.com.au for more details.
What jamb studs do I use for the opening of an INVI Jamb?The manufacturer strongly recommends a timber stud or a 0.75 BMT metal stud on both sides of the opening.
Is the latch plate recessed into the frame?EZC – The latch plate is surface mounted on the INVI Jamb Classic Adjust frame.
SRC – The latch plate is recessed into the frame for the INVI Jamb Single Rebate (SRC).What material are INVI Concept products made from?INVI Concept products are manufactured from highest quality zinc annealed cold-formed steel sections.
Are your frames welded?INVI Jamb frames are not welded and are clipped together using a unique INVI Jamb system that ensures an easy install and smooth finish.
